In stock

Non-Contact Tachometer

Item #
LT2234C

The #LT2234C tachometer uses a laser and reflective tape to measure rotational speeds. It's ideal for testing and troubleshooting motors, engines, gearboxes, fans and compressors.

  • Large 5-digit backlit LCD
  • Auto ranging
  • Wide measuring range
  • Stores and indexes up to 96 measurements
  • Min/max/last memory
  • Auto power off
Specifications
  • Measurement range: 2.5 to 99,999 rpm
  • Measurement accuracy: ±(0.05% + 1 digit)
  • Measurement resolution: 0.1 rpm at and below 999 rpm, 1 rpm at and below 1,000 rpm
  • Maximum distance to target: 20 in. (500mm)
  • Sampling time: 1 second
  • LCD height: 0.7 in. (8mm)
  • Operating temperature: 32° to 122°F (0° to 50°C) @ <80% RH
  • Power source: Three "AAA" batteries (included)
Includes
  • Two 24 in. (600mm) long strips of 1/2 in. (12mm) wide #RT800 adhesive reflective tape
  • Batteries
  • Custom hard plastic carrying case
  • 1-year limited warranty
Dimensions
  • 7.24 x 2.99 x 1.18 in. (184 x 76 x 30mm)

⚠ WARNING: This product can expose you to chemicals including di2-ethylhexylphthalate (DEHP), which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
