In stock

Contact/Non-Contact Tachometer with 40 Reading Memory

Item #
PCT900

The #PCT900 tachometer measures rotational speeds using a contact (wheel) or non-contact (laser) technique. It's ideal for testing and troubleshooting motors, engines, gearboxes, fans and compressors.

  • Includes fittings for measuring the speed of a rotating shaft and the linear speed of a conveyor
  • Also measures any dimension of a stationary object
  • Stores and indexes up to 40 measurements
  • Auto ranging
  • Jumbo 5-digit LCD
  • Min/max/avg memory + data hold
  • Auto power off (can be disabled)
Specifications
  • Measurement ranges: 6 to 25,000 rpm (contact mode), 6 to 99,999 rpm (non-contact mode)
  • Measurement accuracy: ±(0.01% + 1 digit) from 6 to 6000 rpm; ±(0.05% + 1 digit) at and above 6000 rpm
  • Measurement resolution: 0.1 rpm below 1000 rpm; 1 rpm at and above 1000 rpm
  • Linear speed measurement range: 2 to 8202 ft./min (0.6 to 2500m/min)
  • Linear speed measurement accuracy: ±(0.05% + 1 digit)
  • Maximum distance to target: 3.3 ft. (1m)
  • Auto power off: After 30 seconds of inactivity
  • Operating temperature: 32° to 122°F (0° to 50°C) @ <80% RH
  • Weight (without battery): 3.4 oz. 96g)
  • Power source: "9V" battery (included)
Includes
  • Three rubber rpm adaptors
  • Rubber/plastic surface speed wheel
  • 20 in. (500mm) of #RT800 adhesive reflective tape
  • Custom hard plastic carrying case
  • Battery
  • 1-year limited warranty
Dimensions
  • 7.75 x 1.93 x 1.14 in. (146 x 49 x 29mm)

⚠ WARNING: This product can expose you to chemicals including Nickel (metallic), which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
