In stock

Digital Sound Level Meter with Analog Bar Graph

Item #
DSM8930

The #DSM8930 sound level meter is compact and easy to use. It can monitor environmental and industrial noise or provide readings for audio recording or sound system setups.

  • Meets IEC651 TYPE 2 and ANSI S1.4 TYPE 2 standards
  • Large backlit digital LCD plus analog bar graph
  • "A" frequency weighting
  • Fast time weighting
  • Auto ranging
  • Min/Max memory + data hold
  • Analog output for chart recording
  • Auto power off
Specifications
  • Measurement ranges: 40 to 70 dB, 60 to 90 dB, 80 to 110 dB, 100 to 130 dB
  • Measurement accuracy/resolution: 2 dB @ 94dB and 1 kHz/0.1 dB
  • Frequency range: 100 Hz to 8.3 kHz
  • Time weighting time constant: 125 ms
  • Digital display type: 4-digit (4000 count) LCD
  • Digital display refresh period: 160 ms
  • Analog bar graph resolution: 1dB
  • Analog bar graph refresh period: 40 ms
  • Analog output: 0 to 0.707 VACRMS
  • Sensor size and type: 0.5 in. (12.7mm) Electret microphone
  • Auto power off: After 20 minutes of inactivity
  • Operating temperature: 32° to 122°F (0° to 50°C) @ <95% RH
  • Weight: 5.3 oz.
  • Power source: "9V" battery (included)
Includes
  • Wind shield ball
  • Battery
  • 1-year limited warranty
Dimensions
  • 8.1 x 2.4 x 1.6 in. (206 x 61 x 41mm)

⚠ WARNING: This product can expose you to chemicals including di2-ethylhexylphthalate (DEHP), which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
