Class 2 Sound Level Meter with Excel-Formatted Data Logging SD Card

Item #
DSM402SD

The #DSM402D sound data logger is ideal for measuring and documenting environmental and industrial noise for compliance purposes.

  • Large backlit LCD
  • Auto ranging or manual ranging
  • "A" or "C" frequency weighting
  • Fast or slow time weighting
  • Min/max/peak memory + data hold
  • Downloads logs in Excel format
  • Auto power off (can be disabled for data logging)
  • Tripod mount
Specifications
  • Measurement ranges: 30 to 80 dB, 50 to 100 dB, 80 to 130 dB
  • Measurement accuracy (with "A" frequency weighting): 3.5 dB @ 31.5 Hz, 2.5 dB @ 63 Hz, 2 dB @ 125 Hz, 1.9 dB @ 250 Hz, 1.9 dB @ 500 Hz, 1.4 dB @ 1 kHz, 2.6 dB @ 2 kHz, 3.6 dB @ 4 kHz, 5.6 dB @ 8 kHz
  • Frequency range: 31.5 Hz to 8 kHz (Class 2)
  • Data logging sampling time: Adustable from 1 second to 1 hour
  • LCD size: 2.05 x 1.5 in. (52 x 38 mm)
  • Auto power off: After 10 minutes of inactivity
  • Operating temperature: 32° to 122°F (0° to 50°C) @ <85% RH
  • Weight: 1.08 lb. (489g)
  • Power source: Six "AA" batteries (not included) or optional #AC1 9V AC adaptor
Includes
  • Wind shield ball
  • 2GB SD memory card
  • Custom hard plastic carrying case
  • 1-year limited warranty
Dimensions
  • 9.65 x 2.68 x 1.77 in. (245 x 68 x 45mm)
