12-Channel Thermocouple Thermometer with Excel-formatted Data Logging SD Card

Item #
DT4208SD

The #DT4208 12-Channel Thermocouple Thermometer with Excel-formatted Data Logging SD Card is ideal for simultaneously monitoring up to 12 temperatures in a commercial or industrial setting—such as food or chemical processing, HVAC/R, power generation or paper production.

  • Displays up to eight channels at a time; one push of a button switches to Channels 9 through 12Works with and automatically temperature-compensates for six popular thermocouple types: "K", "J", "T", "E", "S" and "R"
  • Combining thermocouple types extends the overall measurement range to -148° to 3092°F (-100° to 1700°C)
  • Includes two #TPK500 thermocouple probes
  • Can automatically log 12 channels of data every day during same period (loop data recording)
  • Big (3.9 in. diagonal) front-panel green backlit LCD is easy to read
  • Min/Max memory + data hold
  • Sampling time is settable from one second to one hour
Specifications
  • Measurement range of thermocouple port: -328° to 2498°F (-200° to 1370°C)
  • Measurement accuracy: ±0.1% (±1°F)
  • Measurement range of included #TPK500 thermocouples: -50° to 500°F (-45° to 260°C)
  • Display size/type: 3.23 x 2.40 in. (82 x 61mm)/LCD
  • Weight: 1.84 lb. (827g)
  • Power source: Eight "AA" batteries (not included) or optional #AC1 9V AC adaptor
Includes
  • Two #TPK500 thermocouple probes
  • 2GB SD memory card
  • Custom hard plastic case
  • 1-year limited warranty
Dimensions
  • 8.86 x 4.92 x 2.52 in. (225 x 125 x 64mm)
